Product Code : ILFE 24
Brand Name : SIGMA EQUIPMENT
We commence ourselves as the well known Manufacturer, Exporter and Supplier of an exclusive assortment of Curing Oven. It is broadly used in offices, schools, industries etc for baking, drying and sterilization of non-volatile products. This oven has a heating unit places side or top of the oven. Our offered oven has a vibrant balanced blower to manage the temperature as well as provide superior insulation hold. To fulfill the different demands of our customers our experienced professionals manufacture this Curing Oven with top grade quality materials and cutting edge technology. We also avail this oven to our customers at negotiable rates. Features:
- Low Maintenance Cost
- Temperature control system
- Long Shelf Life
- Sturdy Construction
Salient Features :
- Box Type Ovens with Trolley consist of demounted sandwich type panels.
- The insulation material used between the panels is 60 Kg/ m3 rock wool and glass wool.
- The heating unit is assigned according to the type of the oven and mounted at the backside of the oven.
- The heating source is provided either by Electric Heater / Diesel or LPG.
- As the burning chamber is separated and insulated inside the oven, there is no flame, fire, soot, black, pollution, dust coming up to the jeans so there is no mark, shade or smell etc. on the jeans. There are special air ducts and blowing vents inside the oven in order to assure homogeneous distribution of hot air through the oven.
- The oven can be easily installed and used on a plain ground. The rail system on the floor of the oven allows an easy entrance and movement for the trolleys.
- The oven reaches to set temperature (~160oC) at start-up within 25-30 minutes. The maximum temperature difference between all the points inside the oven is 30oC. As reaching the set temperature, the automatic temperature limiter is activated so that the set temperature remains constant. Thus, the most suitable working circumstances are obtained.
Dimensions WxDxH Outer Size
Dimensions WxDxH Inner Size
Electric Heater Motor
415v, 3ph, 50Hz, 38.0 Kw, 2.2 Kw
